The complete brewing system mainly includes:

Malt Miller

• -Type: double roller, alloy rollers
• -Rollers distance adjustable
• -Stainless Steel Frame
• -Motor: CE/UL Listed
• Optional:
• Conveyor

Brewhouse

• Vessels:
• Regular: MLT+BKW+HLT.
• Mash/Brew Kettle +Lauter & Whirlpool Tank.
• Others: Mash, Lauter, Brew, Whirlpool, HLT, CLT.
• Heating Method:
• Steam Heating/Electric Heating/ Direct fire/Baine Marie/RIMS/HERMS
• Specifications:
• -With 30% Total Volume
• -Dome top and cone bottom; bottom cone 160 degree
• -Interior Shell: SUS304, T 3.0mm
• -Exterior Shell: SUS304, T 2.0mm
• -Insulation: PU/Rockwool T 100mm
• -100% TIG welding with pure argon gas shield
• -Interior Finish: 0.4~0.6μm/ Mirror Polishing
• -Top mounted manhole
• -360° CIP spraying ball
• -Thermowell with high accuracy temperature sensor: PT100
• -MLT with agitator with motor reducer, CE/UL Listed
• -MLT with side manhole for spent grains
• -MLT with easy-clean and detachable sparging arm
• -MLT with easy-clean and detachable false bottom
• -BKW with tangential inlet for whirlpool function
• Plate Heat Exchanger (China Top Brand)
• -2 stages for Glycol water and City water
• -SUS 304 Plates and frame
• Wort and HLT Pumps:-CE/UL Listed
• Oxygenator
• Brewhouse pipelines and Valves
• SUS 304 Working Platform
• Optional:
• -Grist Case
• -Wort Buffer Tank
• -Platform with Sink
• -Flow meter
• -Pneumatic Valves
• -Others

Beer Fermenting Vessel/Brites

• -Total capacity: with 25% headspace
• -Dome top and cone bottom, bottom cone, (60 degree for BFV)
• -Interior Shell: SUS304, T 3.0mm;
• -Exterior Shell: SUS304, T 2.0mm;
• -Insulation: PU, T100mm
• -100% TIG welding with pure argon gas shield
• -Interior Finish: to 0.4~0.6μm/ Mirror polishing
• -Cooling Jacket: both on cone and cylinder parts, T 1.5mm
• -Top mounted manhole/Side manhole
• -Relief/vacuum valve
• -Dry hop port
• -Thermometer
• -Sample valve
• -Bung apparatus with pressure gauge
• -Test Pressure: 0.3Mpa, Working pressure: 0.15-0.2Mpa.
• -Rotating racking arm on cone with butterfly valve
• -Drainage with butterfly valve
• -CIP arm with 360° spraying ball
• -Thermowell with high accuracy temperature sensor: PT100
• Optional:
• Level Tube
• CO2 Carbonation Stone
• Copper Shell
• Pressurized Hop drop feeder
• Other requirements
• Dimension design

Cooling System

• Glycol water tank
• -Dome top and cone bottom, bottom cone, 160 degree
• -Interior Shell: SUS304, T3.0mm;
• -Exterior Shell: SUS304, T 2.0mm;
• -Insulation: PU, T 100mm
• -100% TIG welding with pure argon gas shield
• -Thermowell with high accuracy temperature sensor: PT100
• Glycol Chiller (China Top Brand)
• -Condenser type: Efficient inner fin coil type
• -Noise level:＜61db
• Glycol Water Pump: CE/UL Listed

CIP Cart

• -Alkali tank
• -Sterilization tank
• -Shell: SUS304; T 2mm
• -Interior Finish: 0.4~0.6μm/Mirror Polishing
• -Pipelines and valves
• -CIP Pump: CE/UL Listed
• -CIP reinforced hose
• Optional
• Heating Elements
• Controller
• Tank added

Control System

PID Control / PLC Control

• -Mashing temperature setting
• -Boiling temperature setting
• -Lautering temperature
• -pumps speed controlling by VFD, DANFOSS
• -Mash agitator speed controlling by VFD, DANFOSS
• -HLT pump controlling
• -Fermentation temperature setting
• -Cooling system Controlling

Other Auxiliary Equipment

• Water treatment RO System
• Steam boiler: Electric/ Gas/oil
• Hop filter tank/Hop tank
• Kegs
• Beer keg washing machine
• Beer keg filling machine
• Beer bottle filling and capping machine
• Beer bottling system
• Beer filter machine

FAQ

• What capacity do you need to brew?
• What kind of heating method do you prefer?
• III. What’s the voltage in your site?
